ITead Studio IBridge 3x3 Keypad Shield


Photo: ITead Studio

Shield URL: IBridge 3x3 Keypad Shield
Tags: button, input, display, lcd
Maker: ITead Studio

IBridge is a 4X4 key-pad shield with a 5110 Graphic LCD interface. It is compatible with Arduino and IFLAT-32, you can plug it on Arduino/IFLAT-32 board directly, and you can get the small development platform with keypad input and Graphic LCD display.

Open Source: No, not OSHW-compliant
License: Proprietary / closed source
Source: Unknown
AREF
GND
D13 / SCK
D12 / MISO
RESET D11 / MOSI ~
3.3V D10 / SS ~
5V D9 ~
GND D8
GND
VIN D7
D6 ~
A0D5 ~
A1D4
A2D3 ~
A3D2
A4D1 / TX
A5D0 / RX
Note:
The spi bus pin description seems to be off from the typical SPI mapping. It could be a documentation error in the datasheet.

Did I make a mistake? Tell me!
